Drum Size |
Flange diameter (inches) |
94 |
Barrel diameter (inches) |
40 |
Barrel length (inches) |
66 |
Cable Capacity |
2 inch (length in feet) |
7758 |
2-1/2-inch (length in feet) |
5000 |
Maximum Cable Size |
Diameter (inches) |
2-1/2 |
Drum Brake Holding Power |
Maximum pounds on fifth layer |
500,000 |
Drum Brake Dimensions |
Diameter (inches) |
86 |
Width (inches) |
10 |
Drum Dog |
Holding power at average drum (pounds) |
610,000 |
Drum Clutch |
An air-operated jaw clutch is mounted on the intermediate shaft |
Approximate Weight |
Single drum (pounds) |
68,700 |
Marine Treatment |
Inorganic zinc over sandblasted frame and
guards with finish coats of marine machinery epoxy on entire machine. |
|
|
|
