Drum Dimensions

Flange diameter

30"

Barrel diameter

14"

Drum length

28"

Spooling Capacity

3/4" Wire Rope

2281'

7/8" Wire Rope

1619'

1 " Wire Rope

1302'

Brakes

Each drum is equipped with a single external contracting band type brake. The brake is air-actuated and complete with a spring set override / parking brake feature.
Static Rating First Layer – 46,500 lbs.

Clutch

Each drum is equipped with a multiple disc, air applied, spring released clutch.

Drum Dog

Each Drum is equipped with an air actuated Drum Dog.

Weight (with standard diesel power)

Double Drum

15,000 lbs

Paint

Winch Frame, guards and all sheet metal work are sandblasted and coated with inorganic zinc, with finish coats of polyurethane marine paint.
