5TUT-16

10TU-22

PUMP

Type


3-stage, centrifugal opposed impeller, split case

2-stage, centrifugal split case

Max. Pressure

400 psi (27.21 Bars)

250 psi (17.01 Bars)

Suction Port x Flange Size

6" (15.24 cm) x 125 lb. ANSI

12" (30.48 cm) x 125 lb. ANSI

Discharge Port x Flange Size

5" (12.7 cm) x 250 lb. ANSI

10" (25.4 cm) x 250 lb. ANSI

Priming

Protek/Hand

--------------

Parallel Operation

Yes (with approval)

Yes (with approval)

ENGINE

Choice of engine models with electric, hydraulic or air starting

FUEL TANK

Capacity

50 gallon (189.25 liter)

183 gallon (692.66 liter)

Removable

YES

YES

DIMENSIONS

Length

15'3" (4.65m)

21'10" (6.67m)

Width

4'4" (1.3m)

6'2" (1.88m)

Height

6'10" (2.08m)

9'10" (3m)

Weight

10,000 lbs. (4,536 kg)

24,980 lbs (11,330.9 kg)

PAINT


Marine painted with inorganic zinc primer.

Marine painted with inorganic zinc primer.

OPTIONS

The 5TUT-16 can also be equipped with either gasoline engine-powered primer or air pump priming equipment, suction and discharge hose, 6 x 5" or 5 x 4" swaged nipple for discharge, 6" foot valve and strainer or a 5" silent valve.
